Single axle trailers all feature spring axles.
Both tandem axle lines have the same quality construction but have different undercarriages and standard features. The differences are detailed below and on the specific trailer pages.
- Two Year Limited Warranty
- 1/8" thick or heavier tubular steel on all trailer frames 3x3 or larger and more...
Tubular Roller Trailers
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| SE-16-1260 | 14-16 | 1260 | 76 | 3x2 | 12 | 4.80x12B | 17'-3" | 11'-1" | 15'-10" |
| SE-16-1510 | 14-16 | 1510 | 76 | 3x2 | 12 | 4.80x12C | 17'-3" | 11'-1" | 15'-10" |
| SE-17-1700 | 15-17 | 1700 | 90 | 3x3 | 16 | ST175/80D13B | 18'-7" | 13'-6" | 16'-10" |
| SE-17-2200 | 15-17 | 2200 | 90 | 3x3 | 16 | ST175/80D13C | 18'-7" | 13'-6" | 16'-10" |
| SE-17-2450 | 15-17 | 2450 | 90 | 3x3 | 16 | ST205/75D14C | 18'-7" | 13'-6" | 16'-10" |
| SE-18-2200 | 16-18 | 2290 | 90 | 3x3 | 16 | ST175/80D13C | 19'-7" | 13'-6" | 17'-10" |
| SE-18-2450 | 16-18 | 2450 | 90 | 3x3 | 16 | ST205/75D14C | 19'-7" | 13'-6" | 17'-10" |
| SE-18-2650 | 16-18 | 2650 | 96 | 4x3 | 16 | ST205/75D14C | 19'-6" | 14'-8" | 18'-0" |
| SE-18-2800 | 16-18 | 2800 | 96 | 4x3 | 16 | ST205/75D14C | 19'-6" | 14'-8" | 18'-0" |
| SE-18-3100 | 16-18 | 3100 | 96 | 4x3 | 20 | ST215/75D14C | 19'-6" | 14'-8" | 18'-0" |
| SE-18-3600B | 16-18 | 36 | 101 | 4x3 | 24 | ST225/75D15D | 20'-4" | 14'-8" | 17'-6" |
| SE-19-2450 | 17-19 | 2450 | 96 | 4x3 | 16 | ST205/75D14C | 20'-5" | 14'-4" | 18'-8" |
| SE-19-2650 | 17-19 | 2650 | 96 | 4x3 | 16 | ST205/75D14C | 20'-6' | 14'-5" | 18'-9" |
| SE-19-2800 | 17-19 | 2800 | 96 | 4x3 | 16 | ST205/75D14C | 20'-6' | 14'-5" | 18'-9" |
| SE-19-3100 | 17-19 | 3100 | 96 | 4x3 | 20 | ST215/75D14C | 20'-9' | 14'-8" | 19'-0" |
| SE-19-3600B | 17-19 | 3600 | 101 | 4x3 | 24 | ST225/75D15D | 21'-4' | 14'-8" | 18'-6" |
| SE-20-2650 | 18-20 | 2650 | 96 | 4x3 | 16 | ST205/75D14C | 21'-3' | 16'-2" | 19'-6" |
| SE-20-2800 | 18-20 | 2800 | 96 | 4x3 | 16 | ST205/75D14C | 21'-3' | 16'-2" | 19'-6" |
| SE-20-3100 | 18-20 | 3100 | 96 | 4x3 | 20 | ST215/75D14C | 21'-6' | 16'-5" | 19'-9" |
| SE-20-3600B | 18-20 | 3600 | 101 | 4x3 | 24 | ST225/75D15D | 22'-1" | 16'-5" | 19'-3" |
| SE-21-3100 | 19-21 | 3100 | 96 | 4x3 | 20 | ST215/75D14C | 22'-6" | 16'-5" | 20'-3" |
| SE-21-3600B | 19-21 | 3600 | 101 | 4x3 | 24 | ST225/75D15D | 23'-1" | 16'-5" | 20'-3" |
| SE-22-3600B | 20-22 | 3600 | 101 | 4x3 | 24 | ST225/75D15D | 23'-6" | 17'-10" | 20'-6" |
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| SE-21T-4100B | 19-21 | 4100 | 96/102 | 4x3 | 24 | ST175/80D13C | 23'-1" | 16'-5" | 20'-3" |
| SE-21T-4400B | 19-21 | 4400 | 96/102 | 4x3 | 28 | ST205/75D14B | 23'-1" | 16'-5" | 20'-3" |
| SE-21T-4800B | 19-21 | 4800 | 96/102 | 4x3 | 32 | ST205/75D14C | 23'-1" | 16'-5" | 20'-3" |
| SE-22T-4100B | 20-22 | 4100 | 96/102 | 4x3 | 24 | ST175/80D13C | 23'-6" | 17'-10" | 20'-8" |
| SE-22T-4400B | 20-22 | 4400 | 96/102 | 4x3 | 28 | ST205/75D14B | 23'-6" | 17'-10" | 20'-8" |
| SE-22T-4800B | 20-22 | 4800 | 96/102 | 4x3 | 32 | ST205/75D14C | 23'-6" | 17'-10" | 20'-8" |
| SE-23T-5400B | 21-23 | 5400 | 96/102 | 5x3 | 36 | ST205/75D14C | 25'-4" | 18'-6" | 22'-6" |
| SE-24T-5400B | 22-24 | 5400 | 96/102 | 5x3 | 36 | ST205/75D14C | 26'-4" | 19'-6" | 23'-6" |
| SE-24T-6000B | 22-24 | 6000 | 96/102 | 5x3 | 40 | ST215/75D14C | 26'-4" | 19'-6" | 23'-6" |
| SE-24T-6400B | 22-24 | 6400 | 101 | 5x3 | 48 | ST205/75D15D | 26'-4" | 19'-6" | 23'-6" |
| SE-26T-5400B | 24-26 | 5400 | 96/102 | 5x3 | 36 | ST215/75D14C | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-6000B | 24-26 | 24-26 | 96/102 | 5x3 | 40 | ST215/75D14C | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-6400B | 24-26 | 6400 | 101 | 5x3 | 48 | ST205/75D15D | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-6800B | 24-26 | 6400 | 101 | 5x3 | 56 | ST205/75D15D | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-7700B | 24-26 | 77 | 101 | 5x3 | 56 | ST225/75D15D | 28'-8" | 21'-6" | 24'-6" |
| SE-26T-8200BB | 24-26 | 82 | 101 | 5x3 | 64 | ST225/75D15D | 28'-8" | 21'-6" | 24'-6" |
| SE-28T-8200BB | 26-28 | 8200 | 101 | 5x3 | 64 | ST225/75D15D | 30'-8" | 21'-6" | 26'-6" |
| SE-28T-9700BB | 26-28 | 9700 | 101 | 6x3 | 64 | LT235/80R16D | 30'-8" | 23'-6" | 26'-6" |
| SE-30T-9700BB | 28-30 | 9700 | 101 | 6x3 | 96 | LT235/80R16D | 33'-4" | 26'-2" | 29'-2" |
| SE-32T-9700BB | 30-32 | 9700 | 101 | 6x3 | 96 | LT235/80R16D | 35'-4" | 26'-2" | 31'-2" |
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| SE-21T-4100BE | 19-21 | 4100 | 96/102 | 4x3 | 24 | ST175/80D13C | 23'-1" | 16'-5" | 20'-3" |
| SE-21T-4400BE | 19-21 | 4400 | 96/102 | 4x3 | 28 | ST205/75D14B | 23'-1" | 16'-5" | 20'-3" |
| SE-21T-4800BE | 19-21 | 48 | 96/102 | 4x3 | 32 | ST205/75D14C | 23'-1" | 16'-5" | 20'-3" |
| SE-22T-4100BE | 20-22 | 4100 | 96/102 | 4x3 | 24 | ST175/80D13C | 23'-6" | 17'-10" | 20'-8" |
| SE-22T-4400BE | 20-22 | 4400 | 96/102 | 4x3 | 28 | ST205/75D14B | 23'-6" | 17'-10" | 20'-8" |
| SE-22T-4800BE | 20-22 | 4800 | 96/102 | 4x3 | 32 | ST205/75D14C | 23'-6" | 17'-10" | 20'-8" |
| SE-23T-5000BE | 21-23 | 5000 | 96/102 | 4x3 | 32 | ST205/75D14C | 24'-6" | 17'-10" | 21'-8" |
| SE-23T-5400BE | 21-23 | 5400 | 96/102 | 5x3 | 32 | ST205/75D14C | 24'-8" | 17'-10" | 21'-10" |
| SE-24T-5400BE | 22-24 | 5400 | 96/102 | 5x3 | 32 | ST205/75D14C | 25'-8" | 18'-10" | 22'-10" |
| SE-24T-6000BE | 22-24 | 600 | 96/102 | 5x3 | 40 | ST215/75D14C | 26'-4" | 19'-6" | 23'-6" |
| SE-24T-6400BE | 22-24 | 6400 | 101 | 5x3 | 48 | ST205/75D15D | 26'-4" | 19'-6" | 23'-6" |
| SE-26T-5400BE | 24-26 | 5400 | 96/102 | 5x3 | 32 | ST205/75D14C | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-6000BE | 24-26 | 6000 | 96/102 | 5x3 | 40 | ST215/75D14C | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-6400BE | 24-26 | 6400 | 101 | 5x3 | 48 | ST205/75D15D | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-6800BE | 24-26 | 6800 | 101 | 5x3 | 56 | ST205/75D15D | 27'-2" | 19'-6" | 24'-4" |
| SE-26T-7700BE | 24-26 | 7700 | 101 | 5x3 | 56 | ST225/75D15D | 28'-8" | 21'-6" | 24'-6" |
| SE-26T-8200BBE | 24-26 | 8200 | 101 | 5x3 | 64 | ST225/75D15D | 28'-8" | 21'-6" | 24'-6" |
| SE-28T-8200BBE | 26-28 | 8200 | 101 | 5x3 | 64 | ST225/75D15D | 30'-8" | 21'-6" | 26'-6" |
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| SE-28TR-10500BBB | 26-28 | 10500 | 101 | 6x3 | 64 | ST205/75D15D | 31'-2" | 24'-2" | 26'-3" |
| SE-28TR-12500BBB | 26-28 | 12500 | 101 | 6x3 | 96 | ST225/75D15D | 31'-2" | 24'-2" | 26'-3" |
| SE-30TR-12500BBB | 28-30 | 12500 | 101 | 6x3 | 96 | ST225/75D15D | 33'-2" | 26'-2" | 28'-3" |
| SE-32TR-12500BBB | 30-32 | 12500 | 101 | 6x3 | 96 | ST225/75D15D | 35'-2" | 26'-2" | 30'-3" |
| SE-32TR-15000BBB | 30-32 | 15000 | 101 | 6x3 | 96 | LT235/80R16D | 35'-2" | 26'-2" | 30'-3" |
Tubular Bunk Trailers
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| S-14-800 | 11-14 | 800 | 63 | 3.2 | 2 | 4.80x8B | 15'-11" | 8'-6" | 13'-9" |
| S-14-1200 | 11-14 | 1200 | 63 | 3x2 | 2 | 4.80x12B | 15'-11" | 8'-6" | 13'-9" |
| S-16-1200 | 14-16 | 1200 | 63 | 3x2 | 2 | 4.80x12B | 17'-5' | 10'-0" | 15'-3" |
| S-16-1260 | 14-16 | 1260 | 76 | 3x2 | 2 | 4.80x12B | 17'-5' | 10'-0' | 15'-3' |
| S-16-1510 | 14-16 | 1510 | 76 | 3x2 | 2 | 4.80x12C | 17'-5' | 10'-0' | 15'-3' |
| S-17-1700 | 15-17 | 1700 | 90 | 3x3 | 2 | ST175/80D13B | 18'-10" | 12'-9" | 17'-1" |
| S-17-2200 | 15-17 | 2200 | 90 | 3x3 | 2 | ST175/80D13C | 18'-10" | 12'-9" | 17'-1" |
| S-17-2450 | 15-17 | 2450 | 90 | 3x3 | 2 | ST205/75D14C | 18'-10" | 12'-9" | 11'-1" |
| S-18-2200 | 16-18 | 2200 | 90 | 3x3 | 2 | ST175/80D13C | 19'-10" | 12'-9" | 18'-1" |
| S-18-2450 | 16-18 | 2450 | 90 | 3x3 | 2 | ST205/75D14C | 19'-10" | 12'-9" | 18'-1" |
| S-18-2800 | 16-18 | 2800 | 96 | 4x3 | 2 | ST205/75D14C | 19'-8" | 13'-7" | 17'-11" |
| S-18-3100 | 16-18 | 3100 | 96 | 4x3 | 2 | ST215/75D14C | 19'-8" | 13'-7" | 17'-11" |
| S-18-3600B | 16-18 | 3600 | 101 | 4x3 | 2 | ST225/75D15D | 20'-3" | 13'-7" | 17'-5" |
| S-19-2450 | 17-19 | 2450 | 96 | 4x3 | 2 | ST205/75D14C | 20'-8" | 13'-7" | 18'-11" |
| S-19-2800 | 17-19 | 2800 | 96 | 4x3 | 2 | ST205/75D14C | 20'-8" | 13'-7" | 18'-11" |
| S-19-3100 | 17-19 | 3100 | 96 | 4x3 | 2 | ST215/75D14C | 20'-8" | 13'-7" | 18'-11" |
| S-19-3600B | 17-19 | 3600 | 101 | 4x3 | 2 | ST225/75D15D | 21'-3" | 13'-7" | 18'-5" |
| S-20-2800 | 18-20 | 2800 | 96 | 4x3 | 2 | ST205/75D14C | 21'-5" | 15'-4" | 19'-8" |
| S-20-3100 | 18-20 | 3100 | 96 | 4x3 | 2 | ST215/75D14C | 21'-5" | 15'-4" | 19'-8" |
| S-20-3600B | 18-20 | 3600 | 101 | 4x3 | 2 | ST225/75D15D | 22'-0" | 15'-4" | 19'-2" |
| S-21-3100 | 19-21 | 3100 | 96 | 4x3 | 2 | ST215/75D14C | 22'-5" | 15'-4" | 20'-8" |
| S-21-3600B | 19-21 | 3600 | 101 | 4x3 | 2 | ST225/75D15D | 23'-0" | 15'-4" | 20'-2" |
| S-22-3600B | 20-22 | 3600 | 101 | 4x3 | 2 | ST225/75D15D | 23'-5" | 16'-9" | 20'-7" |
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| S-21T-4100B | 19-21 | 4100 | 96/102 | 4x3 | 4 | ST175/80D13C | 23'-0" | 16'-4" | 20'-2" |
| S-21T-4400B | 19-21 | 4400 | 96/102 | 4x3 | 4 | ST205/75D14B | 23'-0" | 16'-4" | 20'-2" |
| S-21T-4800B | 19-21 | 4800 | 96/102 | 4x3 | 4 | ST205/75D14C | 23'-0" | 16'-4" | 20'-2" |
| S-22T-4100B | 20-22 | 4100 | 96/102 | 4x3 | 4 | ST175/80D13C | 23'-5" | 17'-9" | 20'-7" |
| S-22T-4400B | 20-22 | 4400 | 96/102 | 4x3 | 4 | ST205/75D14B | 23'-5" | 17'-9" | 20'-7" |
| S-22T-4800B | 20-22 | 4800 | 96/102 | 4x3 | 4 | ST205/75D14C | 23'-5" | 17'-9" | 20'-7" |
| S-23T-5400B | 21-23 | 5400 | 96/102 | 5x3 | 4 | ST205/75D14C | 24'-7" | 17'-9" | 21'-9" |
| S-23T-6000B | 21-23 | 6000 | 96/102 | 5x3 | 4 | ST215/75D14C | 24'-7" | 17'-9" | 21'-9" |
| S-24T-5400B | 22-24 | 5400 | 96/102 | 5x3 | 4 | ST205/75D14C | 25'-7" | 18'-9" | 22'-9" |
| S-24T-6000B | 22-24 | 6000 | 96/102 | 5x3 | 4 | ST215/75D14C | 26'-3" | 19'-5" | 23'-5" |
| S-24T-6400B | 22-24 | 6400 | 101 | 5x3 | 4 | ST225/75D15C | 26'-3" | 19'-5" | 23'-5" |
| S-26T-5400B | 24-26 | 5400 | 96/102 | 5x3 | 4 | ST205/75D14C | 27'-1" | 19'-5" | 24'-3" |
| S-26T-6000B | 24-26 | 6000 | 96/102 | 5x3 | 4 | ST215/75D14C | 27'-1" | 19'-5" | 24'-3" |
| S-26T-6400B | 24-26 | 6400 | 101 | 5x3 | 4 | ST205/75D15D | 27'-1" | 19'-5" | 24'-3" |
| S-26T-6800B | 24-26 | 6800 | 101 | 5x3 | 4 | ST205/75D15D | 27'-1" | 19'-5" | 24'-3" |
| S-26T-7700B | 24-26 | 7700 | 101 | 5x3 | 4 | ST225/75D15D | 28'-7" | 21'-5" | 24'-5" |
| S-26T-8200BB | 24-26 | 8200 | 101 | 5x3 | 4 | ST225/75D15D | 28'-0" | 20'-0" | 23'-10" |
| S-28T-8200BB | 26-28 | 8200 | 101 | 5x3 | 4 | ST225/75D15D | 30'-0" | 20'-10" | 25'-10 |
| S-28T-9700BB | 26-28 | 9700 | 101 | 6x3 | 4 | LT235/80R16D | 30'-0" | 22'-10" | 25'-10 |
| S-30T-9700BB | 28-30 | 9700 | 101 | 6x3 | 4 | LT235/80R16D | 32'-0" | 24'-10" | 27'-10" |
| S-32T-9700BB | 30-32 | 9700 | 101 | 6x3 | 4 | LT235/80R16D | 34'-0" | 24'-10" | 29'-10" |
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| S-21T-4100BE | 19-21 | 4100 | 96/102 | 4x3 | 2 | ST175/80D13C | 22'-11" | 16'-3" | 20'-1" |
| S-21T-4400BE | 19-21 | 4400 | 96/102 | 4x3 | 2 | ST205/75D14B | 22'-11" | 16'-3" | 20'-1" |
| S-21T-4800BE | 19-21 | 4800 | 96/102 | 4x3 | 2 | ST205/75D14C | 22'-11" | 16'-3" | 20'-1" |
| S-22T-4100BE | 20-22 | 4100 | 96/102 | 4x3 | 2 | ST175/80D13C | 23'-4" | 17'-8" | 20'-6" |
| S-22T-4400BE | 20-22 | 400 | 96/102 | 4x3 | 2 | ST205/75D14B | 23'-4" | 17'-8" | 20'-6" |
| S-22T-4800BE | 20-22 | 4800 | 96/102 | 4x3 | 2 | ST205/75D14C | 23'-4" | 17'-8" | 20'-6" |
| S-23T-5000BE | 21-23 | 5000 | 96/102 | 4x3 | 2 | ST205/75D14C | 24'-4" | 17'-8" | 21'-6" |
| S-23T-5400BE | 21-23 | 5400 | 96/102 | 5x3 | 2 | ST205/75D14C | 24'-6" | 17'-8" | 21'-8" |
| S-24T-5400BE | 22-24 | 5400 | 96/102 | 5x3 | 2 | ST205/75D14C | 25'-6" | 18'-8" | 22'-8" |
| S-24T-6000BE | 22-24 | 600 | 96/102 | 5x3 | 2 | ST215/75D14C | 25'-6" | 18'-8" | 22'-8" |
| S-24T-6400BE | 22-24 | 6400 | 101 | 5x3 | 2 | ST225/75D15C | 25'-6" | 18'-8" | 22'-8" |
| S-26T-5400BE | 24-26 | 5400 | 96/102 | 5x3 | 2 | ST205/75D14C | 27'-0" | 19'-4" | 24'-2" |
| S-26T-6000BE | 24-26 | 600 | 96/102 | 5x3 | 2 | ST215/75D14C | 27'-0" | 19'-4" | 24'-2" |
| S-26T-6400BE | 24-26 | 6400 | 101 | 5x3 | 2 | ST205/75D15D | 27'-0" | 19'-4" | 24'-2" |
| S-26T-6800BE | 24-26 | 6800 | 101 | 5x3 | 2 | ST205/75D15D | 27'-0" | 19'-4" | 24'-2" |
| S-26T-7700BE | 24-26 | 7700 | 101 | 5x3 | 2 | ST225/75D15D | 28'-6" | 21'-4" | 24'-4" |
| S-26T-8200BBE | 26-28 | 8200 | 101 | 5x3 | 2 | ST225/75D15D | 28'-6" | 21'-4" | 24'-4" |
| S-28T-8200BBE | 26-28 | 8200 | 101 | 5x3 | 2 | ST225/75D15D | 30'-6" | 21'-4" | 26'-4" |
| Model | Boat Length | Cap. Lbs | O.A.W. | Frame Size | Rollers | Tire Size Minimum | Overall Length | Transom to Bow eye, Min | Transom to Bow eye, Max |
|---|---|---|---|---|---|---|---|---|---|
| S-28TR-10500BBB | 27-28 | 10500 | 101 | 6x3 | 4 | ST205/75D15D | 29'-10" | 22'-10" | 24'-11" |
| S-28TR-12500BBB | 27-28 | 12500 | 101 | 6x3 | 4 | ST225/75D15D | 29'-10" | 22'-10" | 24'-11" |
| S-30TR-12500BBB | 28-30 | 12500 | 101 | 6x3 | 4 | ST225/75D15D | 31'-10" | 24'-10" | 26'-11" |
| S-32TR-12500BBB | 30-32 | 12500 | 101 | 6x3 | 4 | ST225/75D15D | 33'-10" | 24'-10" | 28'-11" |
| S-32TR-15000BBB | 30-32 | 15000 | 101 | 6x3 | 4 | LT235/80R16D | 33'-10" | 24'-10" | 28'-11" |
